Great Plains
Great Plains Terra-Max
With high-quality finishing capabilities, the Terra-Max is a hybrid tillage tool that provides exceptional versatility for various field conditions and weather patterns. The Terra-Max can take producers from vertical to conventional tillage and everything between for both fall and spring applications, addressing a wide variety of needs from sizing residue to finishing capabilities.
Featured on the Terra-Max is the new TurboSpeed™ blade, which achieves optimum soil penetration and break-out at faster operating speeds for impressive tillage results. The TurboSpeed Blade was developed by combining some of the best features from TurboBlade from our highly-successful Turbo-Max and SpeedBlade, featured on the Velocity.
A lengthened frame, opposing left-hand and right-hand rolling spike harrows, and a standard double-basket rear attachment combined with active hydraulic down-pressure, all work together to provide a seedbed-ready, high-quality finish. The Terra-Max also has an optimized frame design and heavier C Shanks to promote consistent blade pressure. For ease of maintenance and added durability, the 7-lip TillXtreme seals prevent debris and “dirt pack” between bearing, housing, and spool.
The Terra-Max is available in 20' to 40' models. Named “Terra”, meaning “Earth,” the Terra-Max hybrid tillage tool is no stranger to the soil and stands ready to achieve exceptional agronomic results season after season.
|
Model Numbers
HT1100-20, HT1100-25, HT1100-30, HT1100-35, HT1100-40 |
|
Product Description Versatile Hybrid Tillage |
|
MODEL INFO |
TERRA-MAX® | ||||
|---|---|---|---|---|---|
| MODELS | HT1100-20 | HT1100-25 | HT1100-30 | HT1100-35 | HT1100-40 |
|
COULTER SPACING |
7.5" | ||||
|
WEIGHT (approx. max weight w/ attachments) |
17,800 lbs | 22,250 lbs |
26,375 lbs |
|
|
|
PTO H.P. REQ (min) |
180-230 | 230-285 |
285-340 |
340-400 |
380-460 |
|
DIMENSIONS | |||||
|
TILLAGE WIDTH |
20' | 25' |
30' |
35' |
40' |
|
TRANSPORT WIDTH |
15' 7" | 15' 7" |
15' 7" |
17' |
17' 7" |
|
TRANSPORT HEIGHT |
9' 4" | 12' 4" |
14' 4" |
14' 7" |
14' 4" |
|
TILLAGE INFO | |||||
|
CENTER SECTION |
12' 3" | 12' 3" |
12' 3" |
|
|
|
1ST WING SECTION |
5' 3" | 7' 9" |
10' 4" |
|
|
|
2ND WING SECTION |
N/A | N/A |
N/A |
|
|
|
Take control of all your adjustment and monitoring needs right at your fingertips with the new Implement Command option for select models of Turbo-Max and the all-new Terra-Max! This system allows you to set, adjust, and monitor your implement right on your ISO-compatible monitor in your tractor cab. |
|
As a versatile hybrid tillage solution, the Terra-Max gives producers the flexibility to easily adapt to ever-changing conditions. The Terra-Max provides a seed-friendly finish, levels soil and removes ruts, sizes residue, and manages chemically-resistant weeds – all with one tool. |
|
New 7-lip TillXtreme™ seals enhance durability and simplify maintenance by preventing dirt and debris from collecting between the bearing, housing, and spool. |
|
By combining some of the best features from TurboBlade from our highly-successful Turbo-Max and SpeedBlade, featured on the Velocity, Great Plains has created the TurboSpeed blade. The TurboSpeed blade achieves soil penetration and break-out from the TurboBlade, combined with faster operating speeds and soil movement using the Speedblade’s profile and low concavity, for impressive tillage results. |
|
Multiple rear hitch options in long, short, ball, and flex-tongue configurations are now available. The rear hitches complement the versatility of the Terra-Max by enabling cover crop, nutrient application, and other light-duty towed attachments. |
|
A lengthened frame, opposing left-hand and right-hand rolling spike harrows, and a standard double-basket rear attachment combined with active hydraulic down-pressure, all work together to provide a seedbed-ready, high-quality finish. |
