Great Plains 706NT
The Great Plains 7' End Wheel No-Till Drill (706NT) offers the perfect balance between smaller drill versatility and larger drill productivity. This unit is at home seeding in a wide variety of applications, from pasture renovation to mine reclamation.
Designed for excellent ground gauging in rugged terrain, the drill’s inline end wheels minimize sideloading on contours and side-hills, dramatically extending the life of the no-till openers.
The 706NT comes standard with a 17-bushel main seed box. A small seeds box can be added, along with either a native grass box, a fertilizer box, or a second seed box. The drill’s other features include 4-speed gearbox(es), mechanical clutch for end-row turns, a calibration crank, central grease bank, and rain-tight lids for maximum seed and fertilizer protection.
|
Model Numbers
706NT |
|
Product Description 7' End Wheel No-Till Compact Drill |
|
MODEL INFO |
7' PULL-TYPE |
|
MODELS |
706NT |
|
PRIMARY DESIGN |
End Wheel No-Till |
|
ROW SPACINGS |
7.5" (19.05 cm) |
|
NUMBER OF OPENERS |
10 |
|
TIRE SIZE |
9.00 x 24 8-ply |
|
ENGINE HP REQUIREMENTS |
55+ |
|
WEIGHT (Approx.) |
3,800 lbs* (1,769 kg) |
|
DIMENSIONS | |
|
WORKING WIDTH |
7' (2.13 m) |
|
WIDTH |
9'10" (3.00 m) |
|
LENGTH (transport) |
13'10" (4.22 m) |
|
CLEARANCE (transport) |
13.5" (34.29 cm) |
|
HEIGHT (transport) |
6'7" (2.0 m) |
|
OPENER INFO | |
|
OPENER SERIES |
06 Series |
|
OPENER TRAVEL |
6.5" (16.51 cm) |
|
OPENER DEPTH RANGE |
0-3.5" (0-8.89 cm) |
|
OPENER DOWN PRESSURE |
90-180 lbs (40.82-81.64 kg) |
|
COULTER |
5/8" Turbo or 5/16" Fluted |
|
COULTER PRE-LOAD |
450 lbs (203 kg) |
|
CAPACITIES | |
|
MAIN BOX CAPACITY |
17.1 bu. |
|
SMALL SEED BOX |
1.68 bu. |
|
NATIVE GRASS BOX |
7 bu. |
|
FERTILIZER |
6.5 cu./ft. |
|
2ND MAIN BOX |
7 bu. |
|
Disengages all drive components, reducing wear and tear during transport. |
|
With the high clearance and end wheel design, the 706NT can virtually go anywhere your tractor can pull it without gouging or bottoming out. |
|
Six-position hitch adjusts to your tractor's hitch height to keep the drill level in planting position. |
|
Provides 18 different positions for accurate seed depth control. |
|
Choices include, from left, single 3"x13" double rib press wheels*; 3"x13" center rib press wheels; single 2"x13" smooth press wheels; 1"x12" double-V press wheels; or wedge-style press wheels that create a pinching action to close the trench. (*Only available by special order through Parts) |
|
Choose between a wide 3/4" wavy coulter, a 5/8" Turbo coulter blade that is aggressive and prepares a mini seedbed ahead of the opener, or a 5/16" fluted coulter blade that penetrates easily to perform minimum tillage. |
|
Large end wheels stay on side hills and maintain accurate seed placement in undulating terrain. Lockout hubs save drive components from wear. |
|
Changing seed rates is quick and effortless with these permanently lubricated, sealed gearboxes. |
|
The 06 Series row unit utilizes the “Fluff and Plant” no-till system with an integrally-mounted coulter to cut residue and prepare a mini seedbed for the trailing double-disc opener. The opener discs are 13.5" in diameter and 4mm thick with 205 triple-lip sealed bearings, and ¼" opener disc lead. Our unique full-length seed tube design and trailing flap control the seed all the way to the bottom of the seed trench where the seed stays in place. |
